Vibration Monitor & Recorder Datawatch IX

This product is in your inquiry basket.




Product inquiry:

Place the product in your personal inquiry cart along with an optional message, which may include notes on the desired configuration.

Description
CE

Monitor for reliable machine monitoring (condition monitoring).

It provides information regarding early warning, alarm status, as well as continuous measured value and data recording.

The Datawatch IX monitor provides a decentralized display of all measured values, as well as remote connectivity to the plant control station.

Benefits:

  • Compact, multicolor monitor and data recorder

  • For centralized and decentralized monitoring of machines and plants

  • Large variety of input signals

Properties
  • Graphical monitor and data recorder with alarm functions

  • 4 isolated or 8 non-isolated inputs (e.g. for connection of 4...20mA transmitters)

  • Configurable inputs: (DC voltage, DC current, 2- and 3-wire thermocouples)

  • 4 relay outputs, 2 dig. Inputs

  • 30 virtual channels

  • Automatic data recording ('Store & Forward‘)

  • Easy operation, also possible without PC

  • Internal flash memory (50MB)

  • USB port for ext. data backup

  • Ethernet network connection (Modbus TCP/IP) for central monitoring (PC, PLC, DCS...)

  • Remote visualization via web server

  • High-quality 3.5" TFT color display for graphical representation of measured values (bar chart, trend, numerical values)

  • Easy control cabinet mounting (DIN rail)

  • Optional pre-wired NEMA4X enclosure made of stainless steel or polycarbonate

Technical features

Characteristics

Technical values

Power supply

24 VDC (9W)

Device protection

(front) IP65

(Rear) IP10

Sampling rate

125ms

Overvoltage protection (inputs)

± 30V RMS

Input impedance (2V range)

> 100 MΩ

Relay outputs

max. 230VAC/2A

Ethernet port (10/100baseT)

RJ45

Temperature range (operation)

0°C ...+55°C

CE
Product versions

Characteristic

Technical values

Dual Input Channels



4 inputs isolated

8 inputs non isolated

4 inputs isolated & 8 inputs non isolated

16 inputs non isolated

Panel Type

Polycarbonate

316 stainless steel

Polycarbonate with transparent window

316 stainless steel with transparent window

others on request

Applications
  • Pumps

  • Compressors

  • Motors and Drives

  • Fans

  • Test benches
