For sporadic speed measurement on a rotating shaft, mobile speed measuring devices are used. The HT-5500 device includes both: For contact measurement, direct mechanical contact to the contact tip of the encoder is required.

For non-contact, optical measurement, reflective marks are bonded to the rotating shaft.

The device allows measurements from 6...99999 rpm.

Benefits:

• The HT-5500 allows contact measurement as well as non-contact speed, circumferential speed, revolution and cycle measurement in one device

• For contact measurement with test probe or non-contact, optical measurement

• Robust and handy hand-held tachometer for measuring:

  • Rotational speed (r/min, r/s)

  • Peripheral speed (m/min)

  • Cumulated revolution (count)

  • Cycle (ms)

• Analog and pulse output for external data evaluation

• Connection for ext. power supply

• For mobile, battery-powered use

• Highly visible 5-digit LCD display with backlight and 10.2 mm line height

• Integrated memory function of the measurement result

• MIN/MAX measurement

• Incl. robust plastic box

  • with adapter, contact tip,

  • circumferential ring,

  • reflex markers and batteries

• Motors and drives Generators

• Engineering

• Test stands and quality

• Service equipment
